Intel Core i5-10400 Processor (12M Cache, up to 4.30 GHz)

Specification

Memory Specifications

Max Memory Size (dependent on memory type) : 128 GB

Memory Types : DDR4-2666

Max # of Memory Channels : 2

Max Memory Bandwidth : 41.6 GB/s

ECC Memory Supported ‡ : No

Advanced Technologies

Intel® Optane™ Memory Supported ‡ : Yes

Intel® Thermal Velocity Boost : No

Intel® Turbo Boost Max Technology 3.0 ‡ : No

Intel® Turbo Boost Technology ‡ : 2.0

Intel vPro® Platform Eligibility ‡ : No

Intel® Hyper-Threading Technology ‡: Yes

Intel® Virtualization Technology (VT-x) ‡ : Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡ : Yes

Intel® VT-x with Extended Page Tables (EPT) ‡ : Yes

Intel® Transactional Synchronization Extensions : No

Intel® 64 ‡ : Yes

Instruction Set : 64-bit

Instruction Set Extensions : Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States : Yes

Enhanced Intel SpeedStep® Technology : Yes

Thermal Monitoring Technologies : Yes

Intel® Identity Protection Technology ‡ : Yes

Intel® Stable Image Platform Program (SIPP) : No

Processor Graphics

Processor Graphics ‡ : Intel® UHD Graphics 630

Graphics Base Frequency : 350 MHz

Graphics Max Dynamic Frequency : 1.10 GHz

Graphics Video Max Memory : 64 GB

4K Support : Yes, at 60Hz

Max Resolution (HDMI 1.4)‡ : 4096x2160@30Hz

Max Resolution (DP)‡ : 4096x2304@60Hz

Max Resolution (eDP - Integrated Flat Panel)‡ : 4096x2304@60Hz

DirectX* Support : 12

OpenGL* Support : 4.5

Intel® Quick Sync Video : Yes

Intel® InTru™ 3D Technology : Yes

Intel® Clear Video HD Technology : Yes

Intel® Clear Video Technology : Yes

# of Displays Supported ‡ : 3

Device ID : 0x9BC8 / 0x9BC5

Essentials

Product Collection : 10th Generation Intel® Core™ i5 Processors

Code Name : Products formerly Comet Lake

Vertical Segment : Desktop

Processor Number : i5-10400

Status : Launched

Launch Date : Q2'20

Lithography : 14 nm

Use Conditions : PC/Client/Tablet

Performance

Specifications

# of Cores : 6

# of Threads : 12

Processor Base Frequency : 2.90 GHz

Max Turbo Frequency : 4.30 GHz

Cache : 12 MB Intel® Smart Cache

Bus Speed : 8 GT/s

Intel® Turbo Boost Technology 2.0 Frequency‡ : 4.30 GHz

TDP : 65 W

Supplemental Information

Embedded Options Available : No

Expansion Options

Scalability : 1S Only

PCI Express Revision : 3.0

PCI Express Configurations ‡ : Up to 1x16, 2x8, 1x8+2x4

Max # of PCI Express Lanes : 16

Package Specifications

Sockets Supported : FCLGA1200

Max CPU Configuration : 1

Thermal Solution Specification : PCG 2015C

TJUNCTION : 100°C

Package Size : 37.5mm x 37.5mm

Security & Reliability

Intel® AES New Instructions : Yes

Secure Key : Yes

Intel® Software Guard Extensions (Intel® SGX) : Yes with Intel® ME

Intel® OS Guard : Yes

Intel® Trusted Execution Technology ‡ : No

Execute Disable Bit ‡ : Yes

Intel® Boot Guard : Yes

Warranty

3 Years
